7μm λ/4 MWIR Zero Order Waveplate

Stock #85-114
S$1,248.00
Qty 1
S$1,248.00
Volume Pricing
Request a Quote
Retardance:
λ/4
Retardance Tolerance:
λ/100 @ 20°C
Retardance Order:
0
Design Wavelength DWL (nm):
7000
Clear Aperture CA (mm):
10.0
Diameter (mm):
25.40
Type:
Crystalline Waveplate
Transmitted Wavefront, P-V:
<λ/8 @ 632.8nm
Construction:
Crystalline
Mount Thickness (mm):
6.0
Parallelism (arcmin):
3
Substrate:
MgF2

Regulatory Compliance

RoHS 2015:
Reach 209:

Product Family Description

  • Ideal for Applications in the 3 – 9μm Range
  • λ/4 and λ/2 Retardance
  • Mounted for Easy Alignment and System Integration

Our zero order Mid-Wave Infrared (MWIR) and Long-Wave Infrared (LWIR) Waveplates are designed for applications in the 3 – 9μm wavelength range. When compared to multiple order waveplates, zero order waveplates provide increased bandwidth and lower sensitivity to temperature change. These waveplates are available with λ/4 or λ/2 retardance in a range of wavelengths, offer efficient retardation over broad spectral ranges, and are ideal for a variety of infrared (IR) applications. Each MWIR and LWIR waveplate is anti-reflection coated, and has been mounted to ease system integration.
